Description:
CSF factories are ISO/TSO certified;CSF Radiators are designed and built to High Performance Standards & sold worldwide for over 50 years-over 30 Million Units Sold!;Our Radiators are carefully engineered & Wind Tunnel Tested in labratory for Cooling Performance Validation;We have over 10,000 different models of Radiators that we manufacture & supply for all the leading brands of vehicles on the road
Features:
OEM specified Copper-Brass Construction
Easy to recore & repair
No risk for coolant contamination and damage to sensitive seals, water pump & thermostat
OEM specified "Single Piece-Deep Drawn" Brass Tanks with Ribs for added Strength & Durability
Tubes-Special coated OEM specified "Double Lock Seam Joints" for Long Life
Fins (Heart of Radiator)-High Performance "Multi-Louvered Design"-OEM Spec
Side Channels-Coated Steel for Strength & Durability
Reinforced Inlet & Outlet Connections with "Thru Pipe Design"
100% leak tested before leaving factory at 150% of operating pressure
Industry Best Packaging-"10 Foot Drop Test" Standard
Drop-in Fit
Built for OEM Cooling-High Performance Transmission Cooler with special Built-in Turbulators
All components are installed, torqued & tested on Radiator during assembly
Box Length (in): 33 3/16
Box Width (in): 25 1/2
Box Height (in): 5 1/2
Box Weight (lbs): 19
Core Length (in): 18 3/4
Core Width (in): 27 1/16
Core Thickness (in): 1 1/8
Inlet Length (in): 26 13/16
Inlet Width (in): 1 3/4
Outlet Length (in): 26 13/16
Outlet Width (in): 1 3/4
Top Hose Fitting (in): 1 1/2 Left
Bottom Hose Fitting (in): 1 3/4 Right
No. Of Rows: 2
Oil Cooler (in): 14 3/16 (high-effeciency Concentric Type)
Core Material: Copper
Tank Material: Brass
Cross-flow/ Down-flow: Down Flow
Radiator Cap Supplied: No
Csf Cap Number: 4501
Hazardous Material: No
Tech Note: Rugged ALL METAL model.
Reference Number: 961,1707,1717,3781733,3781737,3869933,3869941,4016765,4016771,4016777,4016936,4016942,4088473,4089733,4117058,4140165,4140173,4140275,4140621,4140671,4140676,4140977,4164149,4401061,52029115,52029117,52029628,3781736,3781738,3869936,4016735,4016767,4016775,4016935,4016941,4088472,4089582,4089737,4140163,4140167,4140273,4140277,4140623,4140674,4140677,4140978,4164152,52028627,52029116,52029119,52029630,52029630AC,52028627AB,CH3010181,CH3010177,CU1707,8010961,8011707
Package Includes:
Radiator
Compatible With:
1975-1979 Chrysler Cordoba
1979-1980 Chrysler New Yorker Newport
1979-1980 Dodge B200 B300 B100
1981-1994 Dodge B250 B350 B150
1995-1998 Dodge B2500 B3500 B1500
1975-1978 Dodge Charger
1975-1976 Dodge Coronet
1977-1978 Dodge Monaco
1977 Dodge Royal Monaco
1978-1979 Dodge Magnum
1979-1981 Dodge St. Regis
1999-2003 Dodge Ram 2500 Van Ram 3500 Van Ram 1500 Van
