Race Endurance 1.657in OD Conical Springs <br> 2.000in Installed Height, 16 Springs
COMP CAMS
®

Race Endurance 1.657in OD Conical Springs
2.000in Installed Height, 16 Springs

SKU: CCA-7245-16
$639.95

Availability: Out Of Stock

Specification
Product Description Reviews
Description:

As opposed to dual cylindrical spring systems, COMP Cams Dual Conical Valve Springs require no interference fit to dampen spring surge. The self damping characteristic of conical geometry, along with the lower spring kinetic energy of the upper coils, provide a game-changing breakthrough in valve spring design. COMP Cams Dual Conical Valve Springs are constrained at the top and bottom with stepped retainers and spring seats to create separation. The result is that the springs naturally progressive nature can provide outstanding damping without rubbing friction or the associated heat and+D6566 surface damage. These springs are designed for circle track, road Race and drag racing Applications, as well as all-out, high-RPM street/strip hydraulic Roller valve train systems with optimized lifters.

Features:

  • Seat Height: 2.05 IN
  • Seat Pressure: 150 PS
  • Compatible .570" Guide Diameter Spring Seats: 4669-16
  • Coil Bind Height: 1.115 IN
  • Valve Spring Series: Race Endurance
  • Spring Rate: 600
  • Outer Top Spring Outside Diameter: 1.442 IN
  • Compatible Shims: 4756
  • Outer Top Spring Inside Diameter: 1.01 IN
  • Outer Bottom Spring Outside Diameter: 1.657 IN
  • Outer Bottom Spring Inside Diameter: 1.225 IN
  • Number of Springs: 2
  • Inner Spring Inside Diameter: 0.646/0.861 IN
  • Damper: No
  • Compatible Retainer: 716-16


  • Package Includes:

  • Engine Valve Spring Kit
