Description:
CSF factories are ISO/TSO certified;CSF Radiators are designed and built to High Performance Standards & sold worldwide for over 50 years-over 30 Million Units Sold!;Our Radiators are carefully engineered & Wind Tunnel Tested in labratory for Cooling Performance Validation;We have over 10,000 different models of Radiators that we manufacture & supply for all the leading brands of vehicles on the road
Features:
OEM specified Plastic Tank-Aluminum Core Construction
Tanks are made from Virgin Grade Engineered plastic resins, which are "Glass Filled" for added Strength & Durability
Gaskets are made from Special Grade "EPDM" rubber to withstand extreme temperatures of up to -120 Degrees F
Tubes-Welded Type or Latest Generation "B-Tube" Design
Fins (Heart of Radiator)-High Performance "Multi-Louvered Design"-OEM Spec
100% leak tested before leaving factory at 150% of operating pressure
Industry Best Packaging-"10 Foot Drop Test" Standard
Drop-in Fit
High Performance Transmission Cooler with special Built-in Turburlator, when applicable
All components are installed, torqued, & tested on Radiator during assembly
Box Length (in): 39 5/16
Box Width (in): 15 1/16
Box Height (in): 8 1/16
Box Weight (lbs): 14
Core Length (in): 31
Core Width (in): 10 15/16
Core Thickness (in): 1 1/4
Inlet Length (in): 10 15/16
Inlet Width (in): 2 7/16
Outlet Length (in): 10 15/16
Outlet Width (in): 2 7/16
Top Hose Fitting (in): 1 1/4 Right
Bottom Hose Fitting (in): 1 1/2 Left
No. Of Rows: 1
Oil Cooler (in): 7 1/2 (high-effeciency Concentric Type)
Core Material: Aluminum
Tank Material: Plastic
Cross-flow/ Down-flow: Cross Flow
Radiator Cap Supplied: No
Csf Cap Number: 4515
Hazardous Material: No
Tech Note: Economical Lightweight Aluminum core model; Condenser mounts on top bracket, bumper side. Upgraded Heavy Duty Core. 43% Thicker 30mm vs OEM 21mm
Reference Number: 1193,1592,52004921,52006341,52028131,52028134,52030000,52079682,52079693,52080104,52080115,53007135,895 2004 917,895 2029 045,CH3010186,CH3010183,CH3010187,CH3010184,CU1193,8011193
Package Includes:
Radiator
Compatible With:
1991-2001 Jeep Cherokee
