Description:
World exclusive multi-fit model, only from CSF-fits all automatic and manual Wrangler YJ and TJ models. CSF's #1 selling copper/brass Jeep model with over 20,000 sold-a cult favorite among Jeep enthusiasts who wish to keep their original style copper/brass radiator, but desire higher performance and more durability. CSF has over 5 decades of experience manufacturing radiators. So when it comes to keeping your engine cool and your Wrangler running at its finest, a CSF Heavy-Duty Radiator is the obvious choice. CSF has spent years refining and improving their radiator designs. The original style copper/brass construction features ribbed brass end tanks for additional strength and reinforced side end plates and integrated metal core straps to withstand heavy vibration and chassis flex while off-roading. The 3-Row 46mm Heavy-Duty and High-Performance Copper Core offers the best cooling available in a design that is a true "drop-in" fit with no modifications necessary for installation. Whether you are off-roading, towing, or just casually driving your Wrangler, trust the cooling experts at CSF for the best performing, high-quality, and reliable radiators.
Features:
100% leak tested before leaving factory at 150% of operating pressure
All components are installed, torqued & tested on Radiator during assembly
Built for OEM Cooling-High Performance Transmission Cooler with special Built-in Turbulators
Drop-in Fit
Easy to recore & repair
Fins (Heart of Radiator)-High Performance "Multi-Louvered Design"-OEM Spec
Industry Best Packaging-"10 Foot Drop Test" Standard
No risk for coolant contamination and damage to sensitive seals, water pump & thermostat
OEM specified "Single Piece-Deep Drawn" Brass Tanks with Ribs for added Strength & Durability
OEM specified Copper-Brass Construction
Reinforced Inlet & Outlet Connections with "Thru Pipe Design"
Side Channels-Coated Steel for Strength & Durability
Tubes-Special coated OEM specified "Double Lock Seam Joints" for Long Life
Box Length (in): 28 1/16
Box Width (in): 25 5/16
Box Height (in): 5 11/16
Box Weight (lbs): 20
Core Length (in): 18 1/8
Core Width (in): 20
Core Thickness (in): 1 11/16
Inlet Length (in): 20 1/16
Inlet Width (in): 2 1/16
Outlet Length (in): 20 1/16
Outlet Width (in): 2
Top Hose Fitting (in): 1 1/4 Right
Bottom Hose Fitting (in): 1 1/2 Left
No. Of Rows: 3
Oil Cooler (in): 12 (high-effeciency Concentric Type)
Core Material: Copper
Tank Material: Brass
Cross-flow/ Down-flow: Down Flow
Radiator Cap Supplied: No
Csf Cap Number: 4501
Hazardous Material: No
Tech Note: Rugged ALL METAL Heavy Duty, Multifit model; Supplied with snap-on & push-on oil cooler fittings; Removable bracket for applications with A/C.
Reference Number: 1015,1507,2101,2102,52029113 (HD),52029160 (HD),52080180 (HD),52080181 (HD),52080183 AB (HD),52006126 (HD),52028112 (H.D.),52028114 (H.D.),52028120 (H.D.),52028123 (H.D.),8952040229,8952040285,8952040286,8952040287,8952040288,52040229,52040285,52040286,52040287,52040288,52007227,52007228,52004781,52006122,52006123,52006124,52006125,CH3010211,CH3010213,CH3010215,CH3010221,CH3010219,CH3010220,CH3010224,CH3010225,CU1015,CU1507,CU2101,CU2578,8011015,8011507,8012101,8012102
Package Includes:
Radiator
Compatible With:
1987-1995,1997-2004 Jeep Wrangler
