Description:
CSF factories are ISO/TSO certified;CSF Radiators are designed and built to High Performance Standards & sold worldwide for over 50 years-over 30 Million Units Sold!;Our Radiators are carefully engineered & Wind Tunnel Tested in labratory for Cooling Performance Validation;We have over 10,000 different models of Radiators that we manufacture & supply for all the leading brands of vehicles on the road
Features:
OEM specified Plastic Tank-Aluminum Core Construction
Tanks are made from Virgin Grade Engineered plastic resins, which are "Glass Filled" for added Strength & Durability
Gaskets are made from Special Grade "EPDM" rubber to withstand extreme temperatures of up to -120 Degrees F
Tubes-Welded Type or Latest Generation "B-Tube" Design
Fins (Heart of Radiator)-High Performance "Multi-Louvered Design"-OEM Spec
100% leak tested before leaving factory at 150% of operating pressure
Industry Best Packaging-"10 Foot Drop Test" Standard
Drop-in Fit
High Performance Transmission Cooler with special Built-in Turburlator, when applicable
All components are installed, torqued, & tested on Radiator during assembly
Box Length (in): 24 15/16
Box Width (in): 27 5/16
Box Height (in): 5 1/16
Box Weight (lbs): 14
Core Length (in): 18 1/8
Core Width (in): 19 5/8
Core Thickness (in): 1 1/4
Inlet Length (in): 20 3/16
Inlet Width (in): 1 15/16
Outlet Length (in): 20 3/16
Outlet Width (in): 1 15/16
Top Hose Fitting (in): 1 1/4 Right
Bottom Hose Fitting (in): 1 1/2 Left
No. Of Rows: 1
Oil Cooler (in): 12 (high-efficiency Plate Type)
Core Material: Aluminum
Tank Material: Plastic
Cross-flow/ Down-flow: Down Flow
Radiator Cap Supplied: No
Csf Cap Number: 4515
Hazardous Material: No
Tech Note: O.E.M. style Plastic tanks & Aluminum core Multifit model;Supplied with snap-on & push-on oil cooler fittings & special removable bracket;Manufactured with steel crimps to strengthen radiator by 40% over O.E.
Reference Number: 1682,2101,2102,2760,1015,52004781,52006122,52006123,52006124,52006125,52006126,52006127,52006128,52028112,52028114,52028120,52028123,52029113,52029160,52040229,52040285,52040286,52040287,52040288,52080180,52080181,8952040229,8952040285,8952040286,8952040287,8952040288,52080183 AB,CH3010211,CH3010213,CH3010215,CH3010221,CH3010219,CH3010220,CH3010225,CU1015,CU2101,8011682,8012101
Package Includes:
Radiator
Compatible With:
1987-1995,1997-2006 Jeep Wrangler
1997-2006 Jeep TJ
