Description:
CSF factories are ISO/TSO certified;CSF Radiators are designed and built to High Performance Standards & sold worldwide for over 50 years-over 30 Million Units Sold!;Our Radiators are carefully engineered & Wind Tunnel Tested in labratory for Cooling Performance Validation;We have over 10,000 different models of Radiators that we manufacture & supply for all the leading brands of vehicles on the road
Features:
OEM specified Plastic Tank-Aluminum Core Construction
Tanks are made from Virgin Grade Engineered plastic resins, which are "Glass Filled" for added Strength & Durability
Gaskets are made from Special Grade "EPDM" rubber to withstand extreme temperatures of up to -120 Degrees F
Tubes-Welded Type or Latest Generation "B-Tube" Design
Fins (Heart of Radiator)-High Performance "Multi-Louvered Design"-OEM Spec
100% leak tested before leaving factory at 150% of operating pressure
Industry Best Packaging-"10 Foot Drop Test" Standard
Drop-in Fit
High Performance Transmission Cooler with special Built-in Turburlator, when applicable
All components are installed, torqued, & tested on Radiator during assembly
Box Length (in): 33
Box Width (in): 24 3/4
Box Height (in): 6 7/16
Box Weight (lbs): 13
Core Length (in): 17 11/16
Core Width (in): 29 15/16
Core Thickness (in): 7/8
Inlet Length (in): 31
Inlet Width (in): 1 5/8
Outlet Length (in): 31
Outlet Width (in): 1 5/8
Top Hose Fitting (in): 1 3/8 Left
Bottom Hose Fitting (in): 1 3/8 Right
No. Of Rows: 1
Oil Cooler (in): 14 3/4 (high-efficiency Plate Type)
Core Material: Aluminum
Tank Material: Plastic
Cross-flow/ Down-flow: Down Flow
Radiator Cap Supplied: No
Csf Cap Number: 4514
Hazardous Material: No
Tech Note: O.E.M. style Plastic tanks & Aluminum core.
Reference Number: 13207,13548,13116,13117,13118,13206,16041 0P221,16041 0P211,16041 31660,16041 31670,16041-0P260,16041-0P270,16041-0P210,16041-0P220,16041-31630,16410-AZ028,16041-31610,16041-31620,TO3010330,TO3010331,LX3010140,CU13116,CU13117,8013207,221-3167,221-3168
Package Includes:
Radiator
Compatible With:
2010-2015 Lexus RX350 RX450h
2011-2016 Toyota Sienna
