CA Auto Parts

Integrated Windshield Roof LED Light Bar System
21-24 Ford Bronco

SKU:

OL-5888-023
$ 979.16
Availability: In Stock
Compatibility
X

Select Vehicle

Please select Please select Please select Please select Please select

Total:

$979.16
X

Compatibility

Year Make Model Trim Engine
Description:

If you are in the market for a high-mount LED Light bar and want to retain an almost factory look, the new ORACLE Integrated LED Light Bar is for you! While other offerings look obviously after-market or like an after-thought, our Patent-Pending design with its molded cowling integrates into the factory roof line. This product further adds to the rugged and practical style of your 2021 or newer Ford Bronco. Along with blending in with the factory design, the unique cowl design also provides a quieter and more aerodynamic installation compared to traditional LED light bar setups. The polycarbonate housing is designed to match the styling of the factory hardtop but can be installed on soft top Broncos as well, it even retains all functionality when you might want to go topless! The Ford Bronco Integrated LED Light Bar utilizes reflector facing LED technology, elevating it above basic and more common light bars. This reflector system is designed to provide optimized LED light output from the 30 individual 8W LED emitters creating at total of 18,000 raw lumens and a projection distance of over 600 meters. This system also features selectable Amber or White clearance lights. You can select to connect these lights to an Aux Switch, Parking Lights, DRL, or simply leave them disconnected if you prefer not to use the additional clearance light feature on your Bronco.

Specifics and Features:
  • Features and Benefits:
  • Aerodynamic Integrated Housing Design
  • High-Powered Lighting 30x 8W LED Main Light
  • Selectable Amber or White Clearance Lights
  • Precision LED Reflector-Facing Technology
  • DIY Install- No Fabrication/ Modification Required
  • Mounts using Factory Hardware
  • Under/Over Voltage and Reverse Polarity Protection
  • Electronic Thermal Management
  • Innovative Patent-Pending Design
  • Designed and Engineered in the USA
  • LED Lifespan 50,000+ Hours/ 1 Year Warranty
  • Driving Beam Specifications:
  • Raw Lumen Light Output: 18,000LM
  • Effective Lumen Light Output: 14,200LM
  • Peak Intensity: 420,000CD
  • Total Wattage: 240 Watts
  • Total Amp Draw: 14A @12V DC
  • Beam Angle: 40° Driving Beam
  • Max Projection Distance: 1Lux@648M
  • Color Temperature: 5500K-6000K
  • Advanced Optic Design for Optimal Visibility
  • Material Specifications:
  • Outer Housing Material: Polycarbonate
  • Lamp Housing Material: 6030 Aluminum
  • Reflector Material: Plated Polycarbonate
  • Lens: Material: Lexan Polycarbonate
  • Lamp Finish: Polyester Powder Coat
  • Stainless Steel Anti-Fog Breather Valves
  • Molded IP68 Waterproof Connectors
  • Waterproof Rating: IP68 Ingress Protection
  • Part Number : 5888-023

    Package Includes:
  • 1 X Light Bar

    Compatible With:
  • 2021 and up Ford Bronco. This product is not compatible with the 2021 and up Ford Bronco Everglades model with a Pillar Snorkel.

PRODUCT DISCLAIMER

The person that is purchasing this product makes the following representations and acknowledges and agrees to the following terms and conditions:

This off-road race only product ("this Product") is designed and intended for use in organized, amateur and professional racing events, but is limited to closed-course racing and open-course racing that is formally sanctioned by a recognized racing organization involving the motor vehicle in which it is installed (the "Vehicle"). It is not for use on public highways or roads nor is it for recreational off-road use other than solely for competition purposes. The person or entity buying this Product and/or using this Product (the "User") agrees to use the Vehicle solely for competition uses as described herein, and the User acknowledges that the purchase, installation and use of this Product all comply with federal, state and local laws, rules, regulations and ordinances by the User.

The User accepting this disclaimer acknowledges and hereby indemnifies and saves harmless to the manufacture(s), its officers, employees, agents, distributors and dealers for any damages, penalties, fines, expenses or other costs which may arise from the use of this Product and without limiting the generality of the foregoing specifically acknowledges the following:

  • Use of this Product for purposes other than solely for competition is a violation of federal law and may violate applicable state or local environmental, motor vehicle and other laws. The User warrants that this Product shall only be used in sanctioned closed-circuit events.
  • That use of this Product may violate warranties from the manufacturer of the Vehicle or from others.
  • That use of this Product may make the Vehicle unfit or unsafe for the purposes intended or for any purpose and cause personal injury, property damage or death.
  • That the installation of this Product, improper installation of this Product, use of this Product with other components or failure to use this Product in conjunction with other components, could result in or cause personal injury, property damage or death.

THIS PRODUCT IS FOR COMPETITION RACETRACK USE ONLY. ALL OTHER USES ARE CONTRARY TO FEDERAL LAW. IF YOU INTEND THIS PRODUCT FOR HIGHWAY OR NON-COMPETITION RACETRACK OFF-ROAD PURPOSES DO NOT PURCHASE OR INSTALL THIS PRODUCT.
